Model

SDJAS500/SDJAS1000

Manual Stacker with Straddle Legs

Advantage:

● Straddle legs width reach 1300mm(500kg)and1250mm(1000kgs).

● Lifting height from 1500-1600mm.

● With adjustable forged forks.

● High quality steel mast ensures rigidity and durability.

● High efficient pumps makes the control easier to operate.

● Foot and hand controlled lifting function allows the operator to work without having to perform extreme body movements.

● Metal grid protects user from lift chains.

● With safety wheel guard and brake system to ensure safety during operation.

DIMENSION Drawing:

Model		SDJAS500	SDJAS1000
Load capacity/rated load	Q(kg)	500	1000
Load centre distance	c(mm)	500	500
Fork height, lowered	h13(mm)	70	70
Height, mast lowered	h1(mm)	1990	2070
Max. lift height	h3(mm)	1600	1600
Height, mast extended	h4(mm)	1990	2105
Overall length	l1(mm)	1350/1610	1350/1610
Overall width	B1(mm)	1490	1475
Fork dimensions	s/e/l(mm)	48/100/800(1060)	30/100/800(1060)
Width overall forks	b5(mm)	200-745	200-950
Round clearance, laden, below mast	m1(mm)	30	30
Aisle width for pallets 1000x1200 crossways	Ast(mm)	2065(2315)	2072(2322)
Aisle width for pallets 800x1200 lengthways	Ast(mm)	-(2315)	-(2322)
Turning radius	Wa(mm)	1220(1470)	1235(1485)
Lift speed, laden/unladen	mm/time	23/25	20/22
Lowering speed, laden/unladen	mm/s	Manual control	Manual control
Service weight	kg	223	294
