Model

CBD15

Li-ion Powered Pallet Truck

Indoor using type Li-ion powered pallet truck , with similar size as manual pallet truck , offer small turning radius , it is super light and easy to operate.
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15
  • Li-ion Powered Pallet Truck CBD15

Advantage:

Standard :
Option :
●Lithium battery capacity: 24V/20AH.
●Ruyi handle with bully switch.
●High quality emergency switch ( as key switch).
●Split rocker arm makes the equable stress in order to keep the long-time using.
●Driving wheel with horizontal mounted motor, convenience to maintain.
●External battery charger connector, can be charged separately even the battery were used out
●Single fork roller.
●Big battery capacity: 24V/30AH(LITHIUM)
●Entry roller
●Double fork roller

DIMENSION Drawing:

Model



CBD15

Drive: electric (battery type, mains,...), diesel, petrol, fuel gas



Electric

Operator type: hand, pedestrian, standing, seated, order-picker



Pedestrian

Rated capacity/rated load

Q(kg)

1500

Load centre distance

c(mm)

600

Load distance, centre of drive axle to fork

x(mm)

951/1021

Wheelbase

y(mm)

1236/1306

Service weight

kg

114

Axle loading, laden front/rear

kg

410/1204

Axle loading, unladen front/rear

kg

85/29

Tyres: solid rubber, super elastic, pneumatic, polyurethane



Polyurethane (PU)

Tyre size, front



Ф210x75

Tyre size, rear



Ф80x93/Ф80x70

Wheels, number front/rear (x = driven wheels)



1x2(4)

Tread, rear

b11(mm)

390/525

Max. lift height

h3(mm)

110

Height drawbar in driving position min./max.

h14(mm)

635/1200

Height, lowered

h13(mm)

80

Overall length

l1(mm)

1580/1650

Length to face of forks

l2(mm)

430

Overall width

b1/b2(mm)

550/685

Fork dimensions DIN ISO 2331

s/e/l(mm)

53/160/1150(1220)

Fork spread

b5(mm)

550/685

Ground clearance, centre of wheelbase

m2(mm)

27

Aisle width for pallets 1000 x 1200 crossways

Ast(mm)

2180/2250

Aisle width for pallets 800 x 1200 lengthways

Ast(mm)

2050/2085

Turning radius

Wa(mm)

1380/1450

Travel speed, laden/unladen

km/h

4.3/4.5

Lift speed, laden/unladen

m/s

0.016/0.02

Max. gradeability, laden/unladen

%

5/20

Service brake



Electromagnetic

Drive motor rating S2 60 min

kW

0.75

Lift motor rating at S3 15%

kW

0.5

Battery voltage/nominal capacity K5

(V)/(Ah) or kWh

24/20 (lithium battery)

Battery weight

kg

4.5

Sound pressure level at the driver's seat

dB(A)

70

1KG=2.205LB 1INCH=25.40MM
* Option battery: 24V/30Ah
